SMD2727 AD's Outdoor Signs LED Display with 768 x 768 mm LED Panel
for Airport
P6 LED Display Outdoor Signs Quick Detail:
1. 6.144 x 3.072 m screen size;
2. 32 x 16 pcs LED modules in total per screen;
3. 4 x 4 pcs LED modules per cabinet;
4. 768 x 768 mm LED panel size;
5. 1024 x 512 pixels in total;
6. Auto brightness control.
P6 LED Display Outdoor Signs Detail Description:
Each board is composed with 8 x 4 pcs LED panels, with each 768 x 768 mm;
Each cabinet is equipped with 2 pcs Meanwell RSP-320-5 power
supplies, 2 pcs cooling fans;
Power box is equipped, with 30 KW, including OBO lightning
arrester.
P6 LED Display Outdoor Signs Application:
This is installed for outdoor fixed advertising on building, pillar
based, ground, etc.
P6 LED Display Outdoor Signs Specifications:
| Pixel Pitch | 6 mm |
LED Type | SMD2727 |
LED Encapsulation | Nationstar |
PCB | New Light, 1.6 mm thickness |
LED Module Pixel | W 32 × H 32 dots |
LED Module Size | W 192 × H 192 mm |
LED Panel | Iron waterproof cabinet with back door |
LED Panel Size | W 768 × H 768 mm |
Screen Size | W 6.144 × H 3.072 m |
Screen Resolution | W 1024 × H 512 pixels |
Driving Method | 1/8 scan constant current |
Luminance | 7,000 nits with testing by luminance colorimeter |
View angle | 120 degrees |
Power Supply | Meanwell, CB/CE/UL standard |
Power Box | 30 KW |
Video Processor | HDMI, VGA, DVI input signal |
Power and Signal Connector | Linko |
Advantage of LED Screen:
A. Seamless LED screen: rich and colorful, the only large display
device that can be used all day long;
B. Long life: up to 100,000 hours (ten years) or more;
C. Modular structure: the LED display area can be adjusted by
specific requirement. It can be as small as
one square meter, and also as large as several hundred or thousands
of square meters;
D. LED screen display easy to be compatible with computer
interface, rich support software , easy and flexible
operation, clear and stable picture presentation.
E. LED display network: One computer can simultaneously control
multiple displays to play different content.
And the LED display can also work offline. Furthermore, it can
display both text and graphic images, the fonts
are richly varied as well.
Our service
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for the customer.
3. Provide unique and professional solutions based on customer's
requirement.
4. Datasheet and samples offered.
5. Other required services such as special packing design, factory
visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during
production.
3. Free spare parts provided.
After-sale service:
1. Complaint respond period not exceed 24 hours; LED display
maintenance guidance and problem solution
supplied in 48 hours.
2. Warranty: 12-24 months.
3. Free technician training.
4. Full set of documents free of charge, which including LED screen
installation guidance, software operation
manual, easy maintenance manual and control system software CD and so on.
More image of Outdoor Signs:
P6 outdoor screen module
Outdoor screen back view
LED panel
Outdoor signs LED display application
