Brightness PH10 Outdoor LED Screen 6500 nits with MBI5188 Drive IC
Quick Detail:
1. Die-cast aluminum LED box;
2. 640 by 640 mm cabinet size;
3. 64 by 64 dots per cabinet;
4. MBI5188 driving IC;
5. Over 6,500 nits/sq.m;
6. VMS726 video processor.
Detail Description:
It is controlled by synchronization, NOVASTAR controller, high
refresh rate with more than 1200 HZ;
The video processor is JSEE, VMS726, with VGA, DVI, HDMI, S-VIDEO
input signals;
We provide 2 years warranty, and 2% spare parts of the project with
free charge.
Application:
Outdoor LED screen rental is for outdoor rental advertising, easy assembling and disassembling, convenient moving, good displaying effect.
Specifications:
Model | PH10 |
LED Chip | EPISTAR |
LED Type | DIP346 |
Resolution | 10,000 dots/sq.m |
LED Module Pixel | W 16 × H 16 |
LED Module Size | W 160 × H 160 mm |
Cabinet Dimension | W 640 × H 640 mm |
Cabinet Colour | Gray |
Material | Die cast waterproof cabinet |
Drive Method | 1/4 scan constant current |
Luminance | ≥6,500 nits/sq.m |
Refresh Rate | ≥1200Hz |
Drive IC | MBI5188 |
Earth Leakage Current | <2mA |
MTBF | >5,000 hours |
Switch Power | G-energy, 110V and 220V switchable |
Input Signals | HDMI, VGA, DVI, S-VIDEO, etc |
Video Processor | VMS726 |
Package Material | Flight Case |
Software | Novastudio |
![]() |
