    PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P10
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2000sq.m/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance



    PH 10 Big Outdoor Advertising LED Display with 5020 IC 6500 nits Luminance


    Quick Detail:

    1. 4 pcs power supplies per cabinet;
    2. 4 pcs fans each cabinet;
    3. 5.76 by 2.88 m each LED display;
    4. 960 by 960 mm per LED box;
    5. Novastudio operation software;
    6. About 42 kg/pc cabinet.


    Detail Description:

    Each display size is 5.76 by 2.88 m, 5 units such size LED display to be installed in Israel;
    Per cabinet is with pixel of 96 by 96 dots, with 1 pc receiving card, high refresh rate;
    YZK brand power and signal connector for easy assembling and disassembling.


    Application:

    This outdoor advertising LED display would be installed for outdoor street advertising.


    Specifications:

    Pixel Pitch

    PH 10

    LED Chip

    Epistar

    LED Type

    DIP346

    Resolution

    10,000 dots/sq.m

    LED Module Pixel

    W 16 × H 16

    LED Module Size

    W 160 × H 160 mm

    Cabinet Size

    W 960 × H 960 × D 150 mm

    Module Quantity Per Cabinet

    W 6 × H 6 = 36 pcs

    Cabinet Material

    Steel waterproof cabinet with back door

    Driving Method

    1/4 scan constant current

    Brightness

    More than 6,500 CD/sq.m

    Refresh Rate

    ≥1200Hz

    Cabinet Weight

    About 42 kg/pc

    Driving IC

    JXI5020

    Viewing Angle

    100 degrees

    Min. View Distance

    10 m

    Power Supply

    220V / 60HZ

    Brand

    Chuanglian

    Controller

    Novastar

    Package

    Plywood case
