    10 mm Pixel Pitch Outdoor LED Screen Rental with Die-Casting Aluminum

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P10
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2000sq.m/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    10 mm Pixel Pitch Outdoor LED Screen Rental with Die-Casting Aluminum


    10 mm Pixel Pitch Outdoor LED Screen Rental with Die-Casting Aluminum


    Quick Detail:


    1. 640×640 mm cabinet dimension;

    2. 64×64 pixel per cabinet;

    3. 4×4 pcs LED module per cabinet;

    4. EPISTAR LED chip;

    5. MBI5224 driving IC;

    6. Die-casting aluminum LED box.


    Detail Description:


    Each cabinet is composed with 4×4 pcs LED module, about 16 kg;

    Eacy assemble and disassemble;

    Video processor equipped to provide more input signals, like DVI, VGA, HDMI, S-VIDEO, etc.


    Application:


    It is installed for rental advertising, like public concert, exhibition, etc.


    Specifications:


    Type

    PH 10

    LED Chip

    Epistar

    LED Type

    DIP346

    Resolution

    10,000 dots/sq.m

    Module Pixel

    W 16 × H 16

    Module Size

    W 160 × H 160 mm

    Cabinet Size

    W 640 × H 640 mm

    Color

    Yellow

    Material

    Die-casting aluminum waterproof cabinet

    Drive Mode

    1/4 scan constant current

    Brightness

    ≥6800 nits/sq.m

    Refresh Rate

    ≥1200Hz

    Out of Control Dot Rate

    <0.0001

    Earth Leakage Current

    <2mA

    MTBF

    >5,000 hours

    LED Life

    >100,000 hours

    Power Supply

    110V/60HZ and 220V/50HZ interchangeable

    Standard

    CE

    Control Method

    Synchronous control with PC and video processor

    Quality Guarantee

    2 years




    Outdoor LED Screen Rental P10, Die-Cast Outdoor LED Screen Rental, Outdoor LED Screen Rental Video Advertising
