    Static Scan PH20 Perimeter LED Display Board with HDMI DVI VGA Input Signal

    Ask Lasest Price
    Brand Name : Dreamway
    Certification : CE,ROHS
    Model Number : P20
    Price : negotiable
    Delivery Time : 20 days after receiving the deposit
    Payment Terms : T/T
    Supply Ability : 2000sq.m/Month
    • Product Details
    • Company Profile

    Static Scan PH20 Perimeter LED Display Board with HDMI DVI VGA Input Signal



    Static Scan PH20 Perimeter LED Display Board with HDMI DVI VGA Input Signal


    Quick Detail:

    1. 16×8 dots per LED module;
    2. 320×160 mm LED module size;
    3. 1280×960 mm cabinet dimension;
    4. 64×48 dots per cabinet;
    5. DIP546 LED type;
    6. Power and signal cable plug are equipped.


    Detail Description:

    Each LED box is 1280 by 960 mm, about 86 kg/pc;
    Three-core power aviation plug and nine-core signal aviation plug are equipped for easy operation;
    The cabinet is specially made, and you could adjust at different angle as what you want.


    Application:

    It is used for football stadium ads.


    Specifications:

    Pixel Pitch

    20 mm

    LED Composition

    2R1G1B

    LED Encapsulation

    DIP546

    Drive IC

    MBI5024

    LED Module Pixel

    W 16 × H 8

    LED Module Size

    W 320 × H 160 mm

    Cabinet Material

    Steel waterproof cabinet with support and cover

    Driving Mode

    Static scan

    Luminance

    ≥5500 nits/sq.m

    Refresh Rate

    1200~4000 Hz

    Out of Control Dot Rate

    <0.0001

    Earth Leakage Current

    <2mA

    MTBF

    >5,000 hours

    LED Life Span

    >100,000 hours

    Power Supply

    110V/60HZ and 220V/50HZ interchangeable

    Humidity

    10%~90%

    Software

    NovaStudio

    Package

    2 years
