    10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P10
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2000sq.m/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    10 mm Pixel Pitch P10 Outdoor LED Signs With Front Service Synchronous Control


    10 mm Pixel Pitch Outdoor LED Signs with Front Service Synchronous Control


    Quick Detail:


    1. 7.68 × 0.96 m screen size;
    2. 1.28 × 0.96 m cabinet dimension;
    3. Steel waterproof cabinet with frame;
    4. 6 pcs power supplies in a cabinet;
    5. NOVASTAR controller;
    6. Chuanglian brand super-thin power supply.


    Detail Description:


    This screen is composed with 6 pcs cabinets, P10 type, EPISTAR LED chip, 6500 nits;
    Controlled with synchronization, 1 pc receiving card in each cabinet, high refresh rate;
    YZK brand power and signal connector at one side.


    Specifications:


    Pixel Pitch

    10 mm

    LED Chip

    EPISTAR

    LED Module Pixel

    W 16 × H 16

    LED Module Size

    W 160 × H 160 mm

    Screen Size

    W 7680 × H 960 mm

    Cabinet Size (without frame)

    W 1280 × H 960 mm

    Service Way

    Front

    Cabinet Color

    Black

    Cabinet Material

    Steel waterproof cabinet with frame and hydraulic lever

    Drive Method

    1/4 scan constant current

    Brightness

    ≥6500 nits/sq.m

    LED Module in a Cabinet

    W 8 × H 6 = 48 pcs

    Drive IC

    JXI5020

    Earth Leakage Current

    <2mA

    MTBF

    >5,000 hours

    Life Span

    >100,000 hours

    Control Method

    Synchronization with PC

    Controller

    NOVASTAR

    Operation Software

    NOVASTUDIO

    Package

    Plywood case



    Front Service LED Sign, 10 mm Outdoor LED Sign Display, Advertising LED Sign
