    High Resolution 5 mm LED Taxi Top Advertising Aluminum MBI5020 Drive IC

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P5
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 200PCS/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    High Resolution 5 mm LED Taxi Top Advertising Aluminum MBI5020 Drive IC


    High Resolution 5 mm LED Taxi Top Advertising Aluminum MBI5020 Drive IC


    Quick Detail:


    1. 40,000 dots per square meter;

    2. Asynchronous control by 3G;

    3. Aluminum waterproof cabinet with special design;

    4. Acrylic glass at two sides;

    5. Time relay equipped;

    6. 5V 40A power supply.


    Detail Description:


    The cabinet is specially designed with base to connect with roof rack and acrylic glass at the two sides;

    Each power supply is 5V 40A, DC 9~36 V, 4 pcs inside one display;

    3 pcs taxi LED displays in 1 pc plywood case.


    Application:


    Taxi LED display is used for taxi top advertising to show video, graphic, text, message, etc.


    Specifications:


    Type

    P5

    Resolution

    40,000 dots/sq.m

    LED Type

    SMD2727

    LED Composition

    1R 1G 1B

    LED Module (per side)

    W 6 × H 2 = 12 pcs

    LED Module Pixel

    W 32 × H 32 dots

    LED Module Size

    W 160 × H 160 mm

    Screen Measurement

    W 960 × H 320 mm

    Cabinet Measurement

    W 1012 × H 401 × D 190 mm

    Material

    Aluminum made, acrylic glass at two sides

    Colour

    Silver

    Weight

    about 26 kg/pc

    Driving IC

    MBI5020

    Brightness

    Over 6,500 nits/sqm

    Power Supply

    DC 9 ~ 36V

    Output Voltage

    DC 5V

    Video Formats

    AVI, WMV, MPG, MOV, DAT, VOB, MP4, FLV

    Animation Formats

    GIF, SWF

    Picture Formats

    JPG, BMP, WMF

    Control Method

    3G

    3G Mode

    WCDMA

    Package

    Plywood case




    Taxi LED Display P5 SMD2727, Taxi Top LED Display, Taxi Video LED Display
