P5 mm SMD2727 Nationstar led outdoor screen , large led video panels

    Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers

    Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers
    • Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers
    • Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers
    • Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers
    • Buy cheap P5 mm SMD2727 Nationstar led outdoor screen , large led video panels from wholesalers

    P5 mm SMD2727 Nationstar led outdoor screen , large led video panels

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P5
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2000sq.m/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    P5 mm SMD2727 Nationstar led outdoor screen , large led video panels



    P5 mm SMD2727 Nationstar led outdoor screen , large led video panels

    Quick Detail:

    1. Nationstar LED;
    2. SMD2727
    ;
    3. 640
    × 960 mm cabinet size;
    4. Iron waterproof cabinet
    ;
    5. Novastar controller
    ;
    6. Plywood case package
    .


    Detail Description:

    This is SMD2727 LED, Nationstar brand, with about 7,000 high brightness;
    The whole screen size is 7.68 by 1.92 m, 1536 by 384 pixels in total;
    Each cabinet is equipped with 2 pcs fans for good ventilation.


    Application:

    Such outdoor LED display screen is for outdoor advertising, like installed on wall, shopping mall, etc.


    Specifications:

    Pixel Pitch

    5 mm

    LED Type

    SMD2727

    LED Composition

    1R 1G 1B

    Screen Size

    W 7.68 × H 1.92 m

    Resolution

    W 1536 × H 384 pixels

    Module Size

    W 160 × H 160 mm

    Cabinet Size

    W 640 × H 960 × D 145 mm

    Cabinet Weight

    25 kg/pc

    Cabinet Material

    Iron waterproof cabinet with back door

    LED Module Quantity

    W 48 × H 12 = 576 pcs

    Cabinet Quantity

    W 12 × H 2 = 24 pcs

    Best Viewing Distance

    5 ~ 60 m

    Driving Mode

    1/8 scan constant current

    Luminance

    7,000 nits

    View angle

    120 degrees

    Power and Signal Connector

    Linko

    Power Supply

    88 ~ 264VAC

    Brand

    Meanwell

    Control Card

    Novastar

    Warranty

    2 years




    Outdoor HD LED Display, Outdoor Video LED Screen, SMD2727 Outdoor LED Display
