HD 3mm Indoor led screen module SMD2121 LED 192×192 mm 1/32 Scan Drive
Quick Detail:
1. SMD2121 LED type;
2. 111,111 dots/m2;
3. 64×64 dots;
4. 192×192 mm;
5. 1/32 scan constant current;
6. More than 1,200 CD/m2.
Detail Description:
This is 1/32 scan, with 24 pcs 5020 driving ICs, not less than 1,200 nits;
P3 type is with very high resolution, 111,111 LEDs per square meter;
Novastar controller used to operate with synchronization.
Specifications:
Type | P3 |
LED Type | SMD2121 |
LED Composition | 1R 1G 1B |
LED Module Pixel | W 64 × H 64 |
LED Module Size | W 192 × H 192 mm |
Weight | 0.28 kg/pc |
Drive Mode | 1/32 scan constant voltage |
Brightness | More than 1,200 nits |
Driving Voltage | 5V |
Package | Carton case |
High Resolution 3mm LED module, P3 Indoor LED Display Module, Full Color LED Module
![]() |
