    6000 Nits P10 Outdoor Advertising LED Display Board Waterproof 960 × 960 mm

    Ask Lasest Price
    Brand Name : Dreamway
    Model Number : P10
    Certification : CE,ROHS
    Price : negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 2000sq.m/Month
    Delivery Time : 20 days after receiving the deposit
    • Product Details
    • Company Profile

    6000 Nits P10 Outdoor Advertising LED Display Board Waterproof 960 × 960 mm


    6000 Nits P10 Outdoor Advertising LED Display Board Waterproof 960 × 960 mm


    Quick Detail:


    1. SMD3535 Nationstar LED encapsulation;
    2. 1.6 mm thickness PCB
    ;
    3. About 6,000 nits;
    4. 576
    × 288 pixels;
    5. Iron waterproof cabinet with back door;
    6. Novastar controller
    .


    Detail Description:


    Each cabinet is with 960 × 960 mm, equipped with 4 pcs RSP-320-5 power supplies, 4 pcs fans;
    The maximum current is 8 Amp per LED module, with 1,000 W/m2 for max. power consumption;
    3 pcs cabinets are packed in 1 pc plywood case.


    Application:


    This is used for outdoor advertising, fixed installation, totally waterproof.


    Specifications:


    Model

    PH10

    LED Type

    SMD3535

    LED Encapsulation

    Nationstar

    PCB

    1.6 mm thickness

    Module Pixel

    W 32 × H 16 dots

    Module Size

    W 320 × H 160 mm

    Cabinet

    W 960 × H 960 mm

    Material

    Iron waterproof cabinet with back door

    Cabinet Weight

    34 kg/pc

    Drive IC

    SM16106

    Drive Method

    1/2 scan constant current

    Luminance

    6,000 nits

    View angle

    120 degrees

    Power Supply

    88~264V

    Brand

    Meanwell

    Control Card

    Novastar

    Package

    Plywood case



    10 mm Outdoor LED Display Screen, Outdoor Advertising LED Display, LED Display Board
